Throughput Speed 0-300 fpm (Controlled From XPS ProMail Base)

Material Size Minimum (W x L): 3″ x 5″
Maximum (W x L): 15″ x 17″

Material Thickness Up to 1-1/4”

Lamp Type Short-Wave Quartz Infrared, 1600 Watt, 240 Volt, Ruby Glare-Reduction w/ Gold Reflector (Dryer Uses Five Lamps)

Output Load Variable Control 0 to 8,000 Watts

Features Remote Sensor; Material Control Guides

Heat Removal Vacuum System; Adjustable Lamp Height.

Safety Material Guides, Safety Interlocks, Lamp Timeout, Belt Crawl, Tilt-Switch

Duty Cycle 240 million pieces total or 4,000,000 per month over a 5-year life cycle. Lamps rated for 1 year of typical service.

Dimensions 34-39” Deck, 42-47” H x 27” W x 36” D

Weight 200 lbs

Electrical 220VAC Three-Wire Single Phase 34A (requires 50-60A service)
